Eliminate the hassle of measuring. Easy and accurate with Bluetooth, the new standard for temperature measurement!

Do you have any temperature control issues?

The hassle of handwriting records

Writing down your daily records by hand takes time.

Risks of contact measurement

Worried about measuring in dangerous locations

Complexity of data management

Storing and managing paper records is difficult

The Bluetooth-enabled radiation thermometer IR-HA can solve this problem!

One-touch measurement

Measurements are completed instantly at the push of a button

Non-contact measurement

Safe measurement from a distance

Smartphone connectivity

Measurement data is automatically transfer to your smartphone

Features and Benefits

No measurement hassle

Automatic data transfer via Bluetooth
Labor costs reduced by 50%

high accuracy and non-contact

Measurement range from as short as 4 meters
high accuracy measurement of ±0.6% (for temperatures between 1000°C and 1500°C, depending on the measurement temperature)

Real-time recording

Auto-save to SD card
Bluetooth option for real-time data management on smartphone or PC

Usage Scene

Food Industry

Automatic recording of food storage temperature

Manufacturing

Quality control of manufacturing process

Warehouse Industry

Storage environment monitoring

Pharmaceutical Industry

Proper temperature control for pharmaceuticals

specifications

Model	IR-HAINB	IR-HASNB	IR-HAQNB
Measurement range	300℃ to 1000℃	600℃ to 2000℃	600℃ to 2000℃ (2 colors) 400 to 3000℃ (single color wide range)
Measurement accuracy	±6℃	Under 1000℃: ±6℃ 1000℃ or higher but less than 1500℃: ±0.6% of measured value 1500℃ or higher: ±1.2% of measured value	Under 1000℃: ±6℃ 1000℃ or higher but less than 1500℃: ±0.6% of measured value 1500℃ or higher and lower than 2000℃: ±1.2% of measured value Over 2000℃: ±2.4% of measured value
Response time	Within 0.2 seconds
Measured distance	φ20/4000mm
battery	2 alkaline AA batteries (rechargeable batteries can be used) or AC power adapter (sold separately)
Continuous use time	約2時間
Communication method	Bluetooth 5.00 Low Energy
Weight	0.45 kg

Customer testimonials

Food manufacturing company A

Quality Control Department

"Since the introduction, measurement time has been reduced by one third and the accuracy of records has improved. It has been well received by staff."

Manufacturing company B

Factory Management Department

"Real-time monitoring has greatly improved our quality control."

Frequently asked questions

The app can be downloaded free of charge. Customers are responsible for communication costs incurred when downloading and using the app.

It can be used continuously for 2 hours.

Dedicated software allows export in CSV models.

Yes, it can be measured offline.
