Exhibition

[Precise temperature control of the firing furnace]
We provide a system that can achieve precise temperature control and monitoring of continuous firing furnaces used in the production of multilayer ceramic capacitors and other products.

[Find out when it's time to replace your heater]
There is always a risk that operation will stop due to heater malfunction in large furnaces. Therefore, we propose a system that notifies you with an alarm when it is time to replace the heater. It is also compatible with heaters with non-linear resistance characteristic such as SiC heaters.

[high-speed high performance thermal image measurement]
We will be exhibiting a "thermography" that can measure instantaneous temperatures such as flames and arc discharges (frame rate 500Hz), and can even measure through glass windows, measuring up to 2600°C.

[thermal image measurement that can be used in environments up to 200°C]
Durability tests for electronic circuit boards involve placing the board in a temperature-controlled chamber and using multiple thermocouples. However, thermocouples often have limited measurement points and are prone to coming off during testing. Using thermal imaging (thermography) instead can clearly show the temperature distribution on the board, but it is rare to find thermal images that can withstand the effects of a temperature-controlled chamber. Therefore, we provide thermal images that can withstand temperatures up to 200°C.

[Temperature solutions for semiconductor processes]
Temperature measurement, control, and monitoring are essential in the semiconductor manufacturing process. We provide temperature solutions for each process (pre-process).

[HACCP compliant, automatic management]
When managing temperatures based on HACCP, if temperature management for each process is done by hand, the warehouse becomes bulky and it takes time to find evidence if something happens. Therefore, we provide a system that store data in the cloud the moment the temperature is measured.
[Kitchen temperature control system]
Multiple wireless temperature sensors are installed in each room, storage room, etc., and the temperature information is store in the cloud. The store data can be viewed anytime, anywhere using a computer or smartphone.

*In addition to the "Cloud" option, we also offer suggestions for those on a low budget.
*Other products on display include measuring food constituent and detecting adhesive defects in food packaging boxes.

1. "Thermal imaging (thermography)" can measure instantaneous temperatures such as flames and arc discharges (frame rate 500Hz), and can even measure through glass windows, measuring up to 2600°C.
2. Achieving emissivity of 0.995 or higher, this "high emissivity flat blackbody furnace" allows for more accurate calibration of thermal images and radiation thermometer.
3. The era of unified management of measurement information is upon us. Chino's unique "Chino Cloud" and examples of its use.
4. This battery-powered "smart card logger" records data automatically and records it automatically, and when you want to know the data, just bring your smartphone close to it.
5. Chino's technology has been brought together in the "Water Electrolysis Evaluation Device" and "Fuel Cell Evaluation Test Device" to determine the actual performance values of water electrolysis and hydrogen power generation.

• 11/20 (Thu) 11:20 ~ System examples combining "measurement, control and monitoring" provided by Chino
• Friday, November 21st, 11:20am - Chino's new technology for measurement, control and monitoring
* Both are held at Seminar Venue C within the exhibition hall

• ① We will teach you tips on how to adjust PID.
• ② How can you tell the temperature without touching it? radiation thermometer full of mysteries.
• ③ Tips for explaining the meaning of “proofreading” to younger people.
*No prior knowledge is required. Recommended for beginners.
※The timetable is as follows:
11/19 (Wed) ①12:30 ②13:30 ①14:30 ②15:30
11/20 (Thu) ①12:30 ③13:30 ①14:30 ③15:30
11/21 (Fri) ②12:30 ③13:30 ②14:30 ③15:30

1. Improved accuracy of temperature measurement for SiC crystal growth
2. Real-time online concentration monitoring of stripping solution
3. Temperature control during the manufacturing process
4. Wafer deposition temperature control

[What we can provide]
• Proposal and design of monitoring systems
• Implementing "document creation" and "on-site work" in validation
• System inspection and calibration after delivery
• Performing "plans and report creation," "installation and measurement of measuring equipment," and "removal work" for temperature mapping

1. Temperature Monitoring
2. Cloud-based temperature mapping
3. Pharmaceutical/ replay medicine monitoring
4. JCSS calibration and various temperature sensors

1. No construction required! Save energy just by changing the settings?
2. What is the simple heatstroke monitoring system?
3. Wouldn't you like to easily visualize that electricity?

1. Wireless power monitoring for business locations
2. Wireless monitoring system for heatstroke
3. Achieve energy savings simply by reviewing temperature control
4. Efforts towards a decarbonized society
